RAP-404-TAB17U_RAM Tab-Tite Large Tablet Mount with Med

HARDWARE INCLUDED
Assembly Hardware

HOLDER DIMENSIONS
Height Range: 9.5" - 11.75"
Width Range: 6.375" - 8.25"
Depth Range: .13" - 1.1"

CLAMP RANGE
1" - 1.875" diameter
0" - 1.6" flat surfaces

SOCKET-TO-SOCKET LENGTH
4.66"

BALL/SOCKET SIZE
C Size (1.5")

WEIGHT CAPACITY
4 lbs

MATERIALS
Marine-grade aluminum
High strength composite

PACKAGING TYPE
Poly Bag

FEATURES:
Medium version of the RAM Tough-Claw is designed to quickly clamp to round, square, and odd-shaped
rails and bars ranging from 1" to 1.875" in outer diameter; rubber pads provide stable gripping and
protection of mounting surface

Spring-loaded holder secures the iPad (1st, 2nd, 3rd, and 4th Gen) with case and more;
interchangeable end cups allow you to modify the holder when upgrading devices

Includes round ball base and medium length C size double socket arm; ball and socket technology
allows for near-infinite adjustability

Backed by a lifetime warranty


WEIGHT
2.27 lbs.
