RAM-B-182U_RAM Centered Reservoir Cover Double Ball Mou

The RAM-B-182U consists of a centered brake/clutch reservoir cover base, double socket arm and
diamond adapter base. The diamond adapter base has a hole pattern that matches the industry standard
AMPS hole pattern and will connect to a large variety of RAM Mount and third party cradles. Designed
into the mount is a 1" diameter patented rubber ball and socket system with adjustment points at the
base and cradle. With a twist of the arm knob, you can move the reservoir cover mount to your
optimum viewing position.

HARDWARE INCLUDED
(4) M4 x 20mm Machine Screws
(4) M4 x 30mm Machine Screws
(4) M4 x 35mm Machine Screws
(4) Nylon Spacers
(4) M4 Stainless Steel Washers

PRODUCT DIMENSIONS
Overall Height: 5"

SOCKET-TO-SOCKET LENGTH
3"

HOLE PATTERN
2-Hole AMPS: 1.912"

BALL/SOCKET SIZE
B Size (1")

WEIGHT CAPACITY
2 lbs

MATERIALS
Marine-grade aluminum

PACKAGING TYPE
Poly Bag

ADDITIONAL INFORMATION
This mount is not compatible with the 2016 BMW R1200RT.

WEIGHT
0.51 lbs.
