RAM-134-90_RAM 6" Long 90° NPT Pipe Mount with Double B

This mount connects directly to then floor, or any mounting surface with the 2.5" diameter base
which is at 90, 45 or 0 degrees to the 6" long vertical pole. At the top of the pole is a 1.5" ball
attached to the socket of a standard 4 5/8" 1.5" double socket arm. The LapTop tray (NOT included)
connects to a 6.25" x 2" Plate with 1.5" ball that joins to the double socket arm. Lap Top Tray
(RAM-234-1) IS NOT included with the mount. Mounting hardware for the base is not included. The base
unscrews from the pole, allowing the mount to be moved to other locations.

SOCKET-TO-SOCKET LENGTH
4.66"

HOLE PATTERN
3-Hole 120-Degree: 1.812" Diameter
See Drawing

BALL/SOCKET SIZE
C Size (1.5")

WEIGHT CAPACITY
4 lbs

MATERIALS
Marine-grade aluminum

PACKAGING TYPE
Poly Bag

ADDITIONAL INFORMATION
This plate is a universal mounting bracket with a selection of mounting hole locations. In certain
applications additional holes may need to be drilled for proper fit with your electronic device.

WEIGHT
2.9 lbs.
